Douglas F4D-1 Skyray
Douglas F4D-1 Skyray
The Douglas F4D Skyray (later redesignated F-6A Skyray in 1963) was an carrier-based fighter/interceptor built by the Douglas Aircraft Company. Although it was in service for a relatively short time (1956-1964) and never entered combat, it was the first carrier-launched aircraft to hold the world's absolute speed record, at 752.943 mph, and was the first United States Navy and United States Marine Corps fighter that could exceed Mach 1 in level flight. 424 of these planes were produced.

At the end of this page is a list of people who have graciously offered their help. Thank you all very much!

Douglas XF4D-1 Skyray/Bu. 124586
  • Delivered to the United States Navy.
    • First prototype.
    • First flight, January 23, 1951.
    • Assigned to the Naval Air Test Center (NATC), 1952-1953 as 586.
    • Transferred to Naval Weapons Center (NWC) NAF China Lake as 586, 1956.
      • Damaged beyond repair in an accident, January 5, 1956
      • Wreckage sent to the NWC Survivability Lab, January 1956.
      • Destroyed in fire fighting practice.
Douglas XF4D-1 Skyray/Bu. 124586
Douglas XF4D-1 Skyray prototype (Bu. 124586) during carrier trials aboard the USS Coral Sea (CVA-43) in October 1953.
[Source: U.S. Navy]

Douglas XF4D-1 Skyray/Bu. 124587
  • Delivered to the United States Navy.
    • Second prototype.
    • Broke world's air speed record, October 3, 1953.
    • Assigned to Edwards AFB, CA for tests, 1955.
    • Bailed to General Electric for turbojet tests, 1956.
    • Written off, October 19, 1960.
  • Displayed at the Museum of Armament and Technology at NAF China Lake, CA.
  • WARBIRD REGISTY PROFILE

Douglas F4D-1 Skyray/Bu. 130740
*1954: NAF China Lake, CA for tests.
*Bailed to the Douglas Testing Division.
*5/25/1955: Written off at BAR R&D El Segundo, CA. Or on 6/23/1955?

Douglas F4D-1 Skyray/Bu. 130741
*NATC.
*1/21/1958: Struck off charge at O&R NAS Norfolk, VA.

Douglas F4D-1 Skyray/Bu. 130742
*1954: NAF China Lake, CA for tests.
*Bailed to the Douglas Testing Division.
*1957: NATC.
*7/1960: Put into storage at NAF Litchfield Park, AZ.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 130743
*Bailed to the Douglas Testing Division.
*1960: NATC as 743.
*1962: Converted to a DF-6A target drone controller.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 130744
*Used as an aerodynamic demonstrator.
*2/6/1958: Written off at NATC.

Douglas F4D-1 Skyray/Bu. 130745
*1955-60: NWC.
*5/22/1958: Set world time-to-height record.
*10/21/1960: Stalled and crashed during simulated carrier take-off at NAF China Lake, CA. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 130746
  • Delivered to the United States Navy.
    • Assigned to the Naval Air Test Center (NATC), 1955-1956.
    • Written off at NATC, May 24, 1956.
Douglas F4D-1 Skyray/Bu. 130746
Douglas F4D-1 Skyray/Bu. 130746 of the U.S. Navy Naval Air Test Center (NATC) taking off after having been catapulted by the stationary steam catapult at the NATC at Patuxent River, MD, 1956.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 130747
  • Delivered to the United States Navy.
    • Assigned to the Naval Air Test Center (NATC), 1955-1956.
    • Transferred to the NWC, 1956-1958.
    • Transferred to the Naval Air Test Center (NATC), 1959-1962.
    • Written off at NAS Patuxent River, MD, November 7, 1962.
Douglas F4D-1 Skyray/Bu. 130747
NOTS Project ("NOTSNIK") test shape ready for flight on a Douglas F4D-1 Skyray/Bu. 130747, Armitage Field, U.S. National Ordnance Test Station, NAF China Lake, CA, 1958.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 130748
*1955-57: NWC.
*1957: Naval Air Development Unit.
*1960: Pacific Missile Test Center.
*1/19/1961: Struck off charge at NAF Litchfield Park, AZ.
*Was preserved at Pima Air and Space Museum for a while?

Douglas F4D-1 Skyray/Bu. 130749
*FAGU.
*NATC as 749.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 130750
*--info needed.

Douglas F4D-1 Skyray/Bu. 134744
*1962: H&MS-15 as YV-7.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134745
*1957: NATC.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134746
*1959: VMF (AW)-114.
*1965: NATC as 746.
*1/29/1965: Written off at NATC.

Douglas F4D-1 Skyray/Bu. 134747
*1958: VF-213.
*9/3/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134748
*NADU.
*NADC.
*1957: Inspector of Naval Materials Office, at Boston, MA.
*1961: Bureau of Naval Weapons Representative Office, in Waltham, MA.
*1961: Bailed to Raytheon Corporation for Sparrow III missile tests, at NAS South Weymouth, MA.
*1963: Withdrawn from use.
*Was preserved onboard the USS Intrepid Museum.
*Was preserved at Bradley Air Musuem, CT.
*Currently preserved at the Pima Air and Space Museum, AZ.

Douglas F4D-1 Skyray/Bu. 134749
*FAGU as TR-22.
*9/18/1962: Written off at NAS Olathe, KS.

Douglas F4D-1 Skyray/Bu. 134750
*1961: VF-101.
*1/13/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134751
*1/1956: Bureau of Aeronautics, at Baltimore, MD.
*Used as a static test frame.
*4/12/1956: Written off at BAR Balitmore, MD.

Douglas F4D-1 Skyray/Bu. 134752
*1955-56: NWC as 752
*1957: PMTC.
*1958: NAF China Lake, CA for tests.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134753
*1958-59: VMF(AW)-114 as AB-xxx.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134754
*Modified to YF4D-1.
*1957-59: NAOTS Chincoteague, VA as 754.
*1959: NATC.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134755
*1956: VF-74 as C-106.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134756
*1956: VF-74 as C-107.
*1958: VF(AW)-3 as PA-16.
*12/17/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134757
*1956: VC-3 as NP-20.
*1961: VF-162 as AF-102.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134758
*1956: VMF(AW)-115 as AE-1.
*5/8/1956: Crashed at MCAS El Toro, CA during an attempted deadstick landing.

Douglas F4D-1 Skyray/Bu. 134759
  • Delivered to the United States Navy.
    • Bailed to NASA at Ames Research Center as 212, 1956-1959.
    • Transferred to NATC, 1959-1960.
    • Written off at NATC, January 8, 1960.
Douglas F4D-1 Skyray/Bu. 134759
Douglas F4D-1 Skyray/Bu. 134759, used for aerodynamics research at the U.S. National Advisory Committee for Aeronautics (NACA) Ames Research Center, CA, from April 4, 1956 to October 16, 1959.
The three people visible are Don Heinle, Stew Rolls, and Walter Liewar.
[Source: NASA photo A-21303.]

Douglas F4D-1 Skyray/Bu. 134760
*1961: VMF-114.
*10/6/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134761
*6/14/1958: Written off at NAF China Lake, CA.

Douglas F4D-1 Skyray/Bu. 134762
*1957-58: NWC as 762.
*5/14/1958: Crashed near NAF China Lake, CA after flight controls locked up due to crankpin failure.

Douglas F4D-1 Skyray/Bu. 134763
*PMTC.
*Used for Sparrow II missile tests.
*1957-59: NADC.
*1967: NATF as 763, used for barrier tests.

Douglas F4D-1 Skyray/Bu. 134764
*1957: Flight Test Division, at NAS Patuxent River, MD.
*1958: VF(AW)-3.
*MARS-37.
*VMF(AW)-314.
*1958: Put into storage at NAF Litchfield Park, AZ.
*1961: Naval Test Pilot School.
*Currently on display at the Naval Air Test and Evaluation Museum, at Patuxent, MD.

Douglas F4D-1 Skyray/Bu. 134765
*1957: NAF China Lake, CA.
*1957: San Diego, CA.
*12/13/1957: Struck off charge at O&R NAS San Diego, CA.

Douglas F4D-1 Skyray/Bu. 134766
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134767
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134768
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134769
*5/1956: Bureau of Aeronautics, at Dallas, TX.
*NARTU Olathe, KS as 7K-103.

Douglas F4D-1 Skyray/Bu. 134770
*1956: VF-74.
*5/8/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134771
*12/23/1958: Written off at BAR El Segundo, CA.

Douglas F4D-1 Skyray/Bu. 134772
*1959: VF(AW)-3 as PA-14.
*1959: VU-7.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134773
*1959: VF-13 as AK-xxx.
*5/28/1959: Written off. In a deck accident on USS Essex?

Douglas F4D-1 Skyray/Bu. 134774
*FAGU as TR-24.
*1963: NARTU Olathe, KS.
*1/6/1963: Crashed after take-off from NAS Olathe, KS. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 134775
*1956: VF-56.
*7/9/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134776
*1962: VMF-531 as EC-23.
*VMF(AW)-115 as AE-15.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134777
  • Delivered to the United States Navy.
    • Assigned to VC-3 as NP-21 and NP-22, 1956.
    • Transferred to VF-23 as ND-xxx, 1957.
    • Crashed in a residential area of Santa Clara, CA, May 9, 1957.
Douglas F4D-1 Skyray/Bu. 134777
Douglas F4D-1 Skyray/ Bu. 134777 of VC-3.
[Source: Bill Larkins]

Douglas F4D-1 Skyray/Bu. 134778
*1965: NATC as 778.
*1965: Withdrawn from use.

Douglas F4D-1 Skyray/Bu. 134779
*3/25/1958: Written off at BAR El Segundo, CA.

Douglas F4D-1 Skyray/Bu. 134780
*VC-3.
*1956: VF(AW)-3 as NP-23.
*11/19/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134781
*1959: VMF(AW)-114.
*VMF(AW)-115.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134782
*? as C-101.
*1958-59: VMF(AW)-114 as AB-xxx.
*3/21/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134783
*1956: VF-74.
*8/23/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134784
*1956-58: FAWTUPAC as PA-31.
*1958: VF-213.
*1/10/1958: Crashed near New Almaden, CA.

Douglas F4D-1 Skyray/Bu. 134785
*1956: VMF-115 as AE-3.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134786
*VC-3 as NP-24.
*1957: VF-23 as ND-208.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.
*Currently preserved at the National Museum of Naval Aviation at NAS Pensacola, FL.

Douglas F4D-1 Skyray/Bu. 134787
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134788
*1956: FAWTUPAC as PA-34.
*1959: VMF (AW)-114.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134789
*1961-62: H&MS-24.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134790
*1956: FAWTUPAC as PA-35.
*1959: FAGU as TR-25.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134791
*1960: VF-13 as AK-110.
*1962: VF-13 as AK-110.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134792
*1960: VF-101.
*9/19/1960: Written off.

Douglas F4D-1 Skyray/Bu. 134793
*1956: VC-3.
*6/4/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134794
*VF(AW)-3 as NP-26.
*VF-23 as ND-209.
*1959: VF-13 as AK-10.
*VF-13 as AK-101.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134795
  • Delivered to the United States Navy.
    • Assigned to VMF(AW)-542 as WH-13.
    • Transferred to VF-141 as NF-206, 1957.
    • Transferred to H&MS-15, 1959.
    • Transferred to VF-162 as AH-201. 1961.
      • Recoded as AF-101, 1961.
    • Struck off charge at NAF Litchfield Park, AZ, October 30, 1964.
F4D-1 (F-6A) Skyray/Bu. 134795
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134796
*1956: FAWTUPAC as PA-33.
*1957: VF-213 as NP-314.
*1958: FAGU.
*11/18/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134797
*1957: VF-141 as S-203.
*1/4/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134798
*1959: VF-13.
*4/22/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134799
*VMF(AW)-115 as VE-17.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134800
*1958-59: VMF(AW)-114 as AB-xxx.
*3/21/1963: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134801
*1957: VMF(AW)-115.
*7/3/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134802
*1958: FAGUPAC as TR-23.
*1958: NADU as TR-24.
*1961: VF(AW)-3 as PA-32.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134803
  • Delivered to the United States Navy.
    • Assigned to VF-102 Diamondbacks as AJ-109, 1959-1961.
    • Written off, February 20, 1961.
Douglas F4D-1 Skyray/Bu. 134803
Two Douglas F4D-1 Skyrays (Bu. 134803 and 134841) of VF-102 Diamondbacks.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134804
*1957: VMF(AW)-115 as AE-9.
*VMF(AW)-542 as WH-9.
*1959: H&MS-15 as YV-10.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134805
*FAWTUPAC as PA-34.
*1956: VF-141.
*10/22/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134806
  • Delivered to the United States Navy.
    • Redesignated F-6A in 1962.
    • Assigned to VF-141 as S-205, 1956.
  • Transferred to the United States Marine Corps.
    • Assigned to VMF-542 as WH-8.
    • Transferred to VMF(AW)-513.
    • Transferred to VMF(AW)-314.
    • Transferred to VMF(AW)-114.
    • Transferred to NAS Patuxent River, MD for tests, 1962.
    • Transferred to Naval Test Pilot School, 1963-1966.
    • Preserved at the National Museum of Naval Aviation at NAS Pensacola, FL.
  • WARBIRD REGISTY PROFILE
Douglas F4D-1 Skyray/Bu. 134806
Douglas F4D-1 Skyray/Bu. 134806 of VMF(AW)-542 Tigers at MCAS El Toro, CA.
[Source: Robbie Stuart Collection]

Douglas F4D-1 Skyray/Bu. 134807
*1957: VMF(AW)-115 as AE-4.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134808
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134809
*1958: VF-141 as NK-213.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134810
*7/7/1956: Written off at BAR El Segundo, CA.

Douglas F4D-1 Skyray/Bu. 134811
*3/19/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134812
*1956: VMF(AW)-115.
*8/14/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134813
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134814
*1957: VMF(AW)-115 as AE-7.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134815
  • Delivered to the United States Marine Corps.
    • Redesignated F-6A in 1962.
    • Assigned to VMF-115 as AE-2, 1956.
    • Transferred to VMF(AW)-314, 1958.
    • Transferred to NARTU Olathe, KS as 7K-105, 1963.
    • Struck off charge at NAS Olathe, KS, October 10, 1963.
Douglas F4D-1 Skyray/Bu. 134815
Douglas F4D-1 Skyray/Bu. 134815 of VMF(AW)-115 Able Eagles.
[Source: USMC Photo.]

Douglas F4D-1 Skyray/Bu. 134816
*VF-74 as C-102.
*1959: VMF(AW)-114 as AB-211.

Douglas F4D-1 Skyray/Bu. 134817
*1957: VF-23 as ND-214.
*1959: VF-101.
*10/26/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134818
*3/28/1958: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134819
*1958-59: VMF(AW)-114 as AB-xxx.
*1963: VF-101 as xJ-112.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134820
*--info needed.

Douglas F4D-1 Skyray/Bu. 134821
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134822
*1956-57: VMF(AW)-115 as AE-13.
*6/3/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134823
*1961-62: H&MS-24 as EW-1.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134824
*1956: VF-101 as J-104.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134825
*1956: NADU.
*1959: VF-102.
*10/2/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134826
*1957: VMF(AW)-115 as VE-10.
*1964: NARTU Olathe, KS as 7K-112.
*7/19/1964: Crashed in the Manzano Mountains, NM. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 134827
*1960: VF-13 as AK-112.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134828
*VF-162 as AF-103.
*1958-59: VMF(AW)-114 as AB-xxx.
*1959: FAGUPACFLT as TR-20.
*1963: NARTU Olathe, KS as 7K-111.

Douglas F4D-1 Skyray/Bu. 134829
*VF-102.
*1956: VMF-115.
*9/12/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134830
*1959: NATC as 830.
*9/11/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134831
*1956: VF-141.
*12/13/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134832
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134833
*VMF(AW)-513 as WF-4.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134834
*1957: VF-141.
*3/22/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134835
*1957: VF-101.
*6/4/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134836
  • Delivered to the United States Navy.
    • Assigned to VF-162 as AF-105.
    • Recoded as AH-205, 1961.
    • Struck off charge at O&R NAS Jacksonville, FL, December 5, 1961.
  • Preserved at the New England Air Museum at Windsor Locks, CT.
  • WARBIRD REGISTY PROFILE
Douglas F4D-1 Skyray/Bu. 134836
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134837
*1959: VF(AW)-3.
*9/28/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134838
*1961: VMF(AW)-531.
*1/4/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134839
*VF(AW)-3.
*1958-59: VMF(AW)-114 as AB-xxx.
*11/9/1962: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134840
*1958: VMF(AW)-114 as AB-xxx.
*1958: VF(AW)-3.
*12/17/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134841
  • Delivered to the United States Navy.
    • Assigned to VF-102 Diamondbacks as AJ-114, 1959-1960.
    • Struck off charge at NAF Litchfield Park, AZ, April 13, 1964.
Douglas F4D-1 Skyray/Bu. 134841
Two Douglas F4D-1 Skyrays (Bu. 134803 and 134841) of VF-102 Diamondbacks.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134842
*VMF(AW)-114.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134843
*VF-162 as AF-101.
*1962: VF-13 as AK-102.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134844
*1958-59: VMF(AW)-114 as AB-xxx.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134845
*1959: VMF (AW)-114.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134846
*1958-59: VMF(AW)-114 as AB-xxx.
*1961: VF-102.
*5/3/1961: Crashed.

Douglas F4D-1 Skyray/Bu. 134847
*1956: VF-101.
*11/28/1956: Written off.

Douglas F4D-1 Skyray/Bu. 134848
  • Delivered to the United States Navy.
    • Assigned to VF(AW)-3 as PA-6.
    • Transferred to VF(AW)-3 as PA-57, 1959.
    • Struck off charge at NAF Litchfield Park, AZ, April 13, 1964.
Douglas F4D-1 Skyray/Bu. 139163
Two Douglas F4D-1 Skyrays (Bu. 139163 and 134848) of VF(AW)-3 Blue Nemesis at NAS North Island, San Diego, CA, 1959.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134849
*1957: VF(AW)-3 as TT-21.
*1957: VF-23.
*9/26/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134850
*1957: VF(AW)-3 as NP-22.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134851
*VMF(AW)-542 as WH-7.
*1959: H&MS-15 as YV-6.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134852
*1959: VF-51.
*5/18/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134853
*1957: Bailed to the Douglas Testing Division.
*1960: NWC.
*4/1961: Put into storage at NAF Litchfield Park, AZ.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134854
*Converted to NF-6A.
*1959-64: NATF as 1.
*3/23/1964: Written off.

Douglas F4D-1 Skyray/Bu. 134855
*1957: VF-141.
*10/7/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134856
*1957-58: VF-74 as AL-211.
*1959: VF-101.
*1959: VX-3.
*1959: NATC.
*1961-62: NMC as 856.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134857
*1961: VMF(AW)-114.
*6/5/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134858
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134859
*VF-74.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134860
  • Delivered to the United States Navy.
    • Assigned to VF-74 as AF-114.
    • Transferred to FAWTULANT, 1957.
    • Transferred to VF-162?
    • Transferred to VF-13, 1960.
    • Written off, September 26, 1960.
Douglas F4D-1 Skyray/Bu. 134860
F4D-1 Skyray/Bu. 134860 with its nose inside a wheeled electronics stand at NAS Oceana, VA, 1958
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134861
*VF-101 as AD-103.
*1957: FAWTULANT.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134862
*1958: VX-3.
*8/20/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134863
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134864
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134865
*VMF(AW)-531 as EC-19.
*1957-58: VX-3 as XC-46.
*4/14/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134866
    Delivered to the United States Navy.
    • Assigned to VF-141 as NF-203, 1956.
      • Recoded as NK-203, 1958-1959.
    • Struck off charge at O&R NAS Jacksonville, FL, November 14, 1963.
Douglas F4D-1 Skyray/Bu. 134866
F4D-1 Skyray/Bu. 134866 of VF141 on the flight deck of USS Bon Homme Richard (CVA-31) with an HUP-2 helicopter of HU-1 and FJ-3 Fury aircraft of VF-51, 1956.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134867
*1958: VF-141.
*8/14/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134868
*1957-58: VF-74 as AL-204.
*1959: VF-102.
*7/29/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134869
*1957: ? as NF-201.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134870
  • Delivered to the United States Navy.
    • Assigned to VF-74 Be-Devilers.
    • Transferred to VF-101 as AJ-00, 1960.
    • Transferred to VF-102 as AJ-00, 1960.
    • Written off, November 20, 1960.
Douglas F4D-1 Skyray/Bu. 134870
Aircraft of Carrier Air Group 17 (CVG-17) on the carrier USS Franklin D. Roosevelt (CVA-42) during that carrier's deployment to the Mediterranean between July 1957 and March 1958.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134870
Maintenance on a APQ-50A radar of F4D-1 Skyray/BuNo 134870 of VF-74 Be-Devilers, Carrier Air Group 17 (CVG-17), onboard the USS Franklin D. Roosevelt (CVA-42).
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134871
*1959: VMF (AW)-114.
*1959: VF-13 as AK-xxx.
*8/22/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134872
*1959: VF-101.
*9/14/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134873
*VF-102.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134874
*1959-61: VF-13 as AK-115.
*VMF(AW)-531 as EC-16.

Douglas F4D-1 Skyray/Bu. 134875
*1959: VF-141 as NK-205.
*VF-141 as NF-205.
*1962: PMTC as 875.
*11/30/1962: Written off at NAS Point Mugu, CA.
*Was preserved in a city park in Oxnard, CA for a while.
*Salvaged at NAF China Lake, CA.

Douglas F4D-1 Skyray/Bu. 134876
*1957: VF-141 as NF-205.
*1957: VF-101 as AP-101.
*12/11/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134877
*VF-23 as ND-201.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134878
*1959: VMF (AW)-114.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134879
*1957: VF-74 as AL-206.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134880
  • Delivered to the United States Navy.
    • Redesignated F-6A in 1962.
    • Assigend to VF-141 as NF-206, 1958.
    • Struck off charge at NAF Litchfield Park, AZ, April 13, 1964.
Douglas F4D-1 Skyray/Bu. 134880
Douglas F4D-1 Skyray/Bu. 134880 of VF-141 Iron Angels on the deck of the
USS Bon Homme Richard (CVA-31) in 1957.
[Source: U.S. Navy Photo.]

Douglas F4D-1 Skyray/Bu. 134881
*1958: VF-141.
*10/15/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134882
*1959: VMF (AW)-114.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134883
*1959: VMF (AW)-114.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134884
  • Delivered to the United States Navy.
    • Flew as NF-207, 1957.
    • Assigned to VF-141 as NK-207, 1959.
    • Written off, February 3, 1959.
Douglas F4D-1 Skyray/Bu. 134884
Douglas F4D-1 Skyrays (Bu. 139165 & 134884) of VF-141 ready to launch from the USS Ranger (CVA 61), 1959.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134885
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134886
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134887
*1958: VF-23.
*7/10/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134888
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134889
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134890
*VF-23 as ND-xxx.
*1961: VF-101.
*8/25/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134891
*1958: VF-23 as NL-206.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134892
*VF-74 as xx-207.
*1958: VMF(AW)-114.
*10/8/1958: Crashed near MCAS Cherry Point, NC. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 134893
*VF(AW)-3 as PA-1.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134894
*VMF(AW)-115.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134895
*1959: VMF(AW)-115 as VE-16.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134896
*1957: VF-101.
*9/24/1957: Crashed into the North Atlantic after a midair collision with F4D-1 134902 off the coast of Norway.

Douglas F4D-1 Skyray/Bu. 134897
*VMF(AW)-115.
*VMF(AW)-531.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134898
*1957: VF(AW)-3 as PA-32.
*1961: VF(AW)-3 as PA-2.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134899
*1957: VF-101.
*11/8/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134900
*1959: FAGU.
*8/25/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134901
*1958: VF-101.
*12/1/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134902
*1957: VF-101.
*9/24/1957: Crashed into the North Atlantic after a midair collision with F4D-1 134896 off the coast of Norway.

Douglas F4D-1 Skyray/Bu. 134903
*1958: VF-101.
*8/13/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134904
*1957: VF-141 as NF-211.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134905
*FAWTUPAC as PA-34.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134906
*1959: VMF (AW)-114.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134907
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134908
*1958: FAWTUPAC as PA-35.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134909
*VMF(AW)-115 as VE-15.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134910
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134911
*1957: VF-213 as NP-310.
*11/16/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134912
*VMF(AW)-115.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134913
*1958: VF-101.
*1/28/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134914
*VMF(AW)-531.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134915
*1959: VF-101.
*12/17/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134916
*1958-59: VMF(AW)-114 as AB-211.
*7/24/1959: Crashed into the Mediterranean Sea after pilot inadvertently turned off the engine. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 134917
*1958: VF-101 as AD-112.
*1961-62: VF-62 as AF-109.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134918
*--info needed.

Douglas F4D-1 Skyray/Bu. 134919
*VF-13 as AK-101.
*1963: Put into storage at NAF Litchfield Park, AZ.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134920
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134921
*1959-60: VF-102 as AJ-112.
*1963: NARTU Olathe, KS.
*2/2/1963: Written off at NAS Olathe, KS.

Douglas F4D-1 Skyray/Bu. 134922
*1958-59: VMF(AW)-114 as AB-xxx.
*VMF(AW)-115.
*VMF(AW)-531 as EC-22.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.
*Used as a refueling pit training aid at NAS Miramar, CA after being struck off charge.

Douglas F4D-1 Skyray/Bu. 134923
*1958-59: VF-102 as AK-104.
*1960: VF-102.
*2/28/1960: Written off.

Douglas F4D-1 Skyray/Bu. 134924
*VF-102.
*7/18/1960: Crashed on flight deck. Repaired?
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134925
*1958: VF-101 as AP-102.
*2/14/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134926
*1957: VF-102.
*11/7/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134927
*1958: VF-102 as AK-111.
*1958-59: VMF(AW)-114 as AB-xxx.
*1959-60: VF-102 as AJ-10x.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134928
*1957: VMF(AW)-115.
*11/13/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134929
*VF-102 as AQ-102.
*1959: VF-102 as AK-102.
*2/25/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134930
*1960: NADU as 7.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134931
*1959-61: NATF.
*1965: Stricken off charge at NAS Lakehurst, NJ.

Douglas F4D-1 Skyray/Bu. 134932
*6/26/1957: Written off at BAR El Segundo, CA.

Douglas F4D-1 Skyray/Bu. 134933
*1958-59: VF-102 as AK-103.
*1960-61: VF-102 as AJ-103.

Douglas F4D-1 Skyray/Bu. 134934
*1958: VF-101.
*5/15/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134935
*1957: VF-102.
*12/6/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134936
*VF-103?
*1957: ? as AK-105.
*1959-60: VF-102 as AJ-1xx.
*1961: VF-102 as AJ-105.
*1963: NARTU Olathe, KS as 7K-114.
*Used at the Emily Griffith Aircraft Training Facility.
*Currently preserved at the Pueblo Weisbrod Museum at Pueblo, CO, registered as �N4263�.

Douglas F4D-1 Skyray/Bu. 134937
*1959: VF-102.
*1/10/1959: Written off.

Douglas F4D-1 Skyray/Bu. 134938
*1957: NADU as 8.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134939
*1957: VF-213.
*9/30/1957: Written off.

Douglas F4D-1 Skyray/Bu. 134940
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134941
*VF(AW)-3 as PA-32.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134942
*5/12/1965: Struck off charge at NAS Olathe, KS.

Douglas F4D-1 Skyray/Bu. 134943
*6/26/1957: Written off at BAR El Segundo, CA.

Douglas F4D-1 Skyray/Bu. 134944
*1958: VF-102.
*3/17/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134945
*1964: NARTU Olathe, KS as 7K-104.

Douglas F4D-1 Skyray/Bu. 134946
*VF-162 as AF-102.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134947
*VF-213 as NP-301.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134948
*VMF(AW)-115 as VE-5.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 134949
*1960: VF-13 as AK-113.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134950
*VMF(AW)-115.
*4/4/1962: Struck off charge at O&R NAS Norfolk, VA.
*Currently preserved at NAS Oceana Air Park at NAS Oceana, VA, falsely marked as �133633�.

Douglas F4D-1 Skyray/Bu. 134951
*VMF(AW)-115.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134952
*1958: VF-213 as NL-310.
*1960: VX-4 as XF-12.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134953
*1959: VMF(AW)-114 as AB-xxx.
*1960: VF-13 as AK-105.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134954
*VF(AW)-3 as PA-4.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134955
*VF-23 as ND-202.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134956
*1958-59: VMF(AW)-114 as AB-xxx.
*1959: VF-74 as AF-109.
*1961: VF-101.
*6/14/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134957
*VMF(AW)-115.
*1961: VF-162.
*8/15/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134958
  • Delivered to the United States Marines Corps.
    • Redesignated F-6A in 1962.
    • Struck off charge at O&R NAS Jacksonville, FL, November 14, 1963.

Douglas F4D-1 Skyray/Bu. 134959
  • Delivered to the United States Marines Corps.
    • Redesignated F-6A in 1962.
    • Assigned to VF-102 Diamondbacks as AJ-110, 1959-1961.
      • Recoded as AQ-110.
Douglas F4D-1 Skyray/Bu. 134959
Douglas F4D-1 Skyray/Bu. 134959 of VF-102 Diamondbacks shortly before lanching from the USS Forrestal (CVA-59), 1961.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 134960
  • Delivered to the United States Marines Corps.
    • Redesignated F-6A in 1962.
    • Assigned to VMF(AW)-114 Death Dealers as AB-209, 1958-1959.
    • Struck off charge at NAF Litchfield Park, AZ, October 30-1964.
Douglas F4D-1 Skyray/Bu. 134960
Three Douglas F4D-1 Skyray (Bu. 134960, Bu. 139042 & Bu. 139051) of VMF(AW)-114 Death Dealers on the catapults of the USS Franklin D. Roosevelt (CVA-42), 1959.
[Source: USMC Photo.]

Douglas F4D-1 Skyray/Bu. 134961
*1958: VF-213.
*9/3/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134962
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134963
*1959: VX-4 as XF-15.

Douglas F4D-1 Skyray/Bu. 134964
*1958-59: VMF(AW)-114 as AB-xxx.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134965
*VMF(AW)-115.
*VMF(AW)-531 as EC-19.
*1961: VF-162.
*8/28/1961: Written off.

Douglas F4D-1 Skyray/Bu. 134966
*NADC.
*VF-213.
*VF-162.
*VMF(AW)-115.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 134967
*1958: VF-213 as NP-305.
*VF(AW)-3 as PA-25.
*VMF(AW)-115.

Douglas F4D-1 Skyray/Bu. 134968
*1957-58: VF-102 as AQ-109.
*7/20/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134969
*VMF(AW)-115.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134970
*1958: VMF(AW)-314 as VW-15.
*1958: VMF(AW)-542.
*11/19/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134971
*1958: VMF(AW)-115.
*4/25/1958: Written off.

Douglas F4D-1 Skyray/Bu. 134972
*1958-59: VMF(AW)-114 as AB-207.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 134973
*1961: VF-13.
*2/11/1961: Written off.

Douglas F4D-1 Skyray/Bu. 139030
*VF(AW)-3 as PA-21.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139031
*1959: VF-13 as AK-11.
*1960-61: VF-13 as AK-111.
*1961: VF-13 as AK-101.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139032
*1959: VMF (AW)-114.
*1960: VF-13 as AK-107.
*1962: VF-13 as AK-104.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139033
*1960: VMF(AW)-531.
*10/4/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139034
*1958: VMF(AW)-114.
*6/28/1958: Crashed on take-off from MCAS Cherry Point, NC. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 139035
*1958-59: VMF(AW)-114 as AB-206.
*8/19/1959: Crashed into the Mediterranean Sea after suffering an engine flameout during landing attempt on CVA-42. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 139036
*1958: VMF(AW)-115.
*11/8/1958: Written off.

Douglas F4D-1 Skyray/Bu. 139037
*1959: VF-13.
*6/11/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139038
*VMF(AW)-115.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139039
*VMF(AW)-115.
*VMF(AW)-531 as EC-17.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139040
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139041
*1958: VF-213 as xx-311.
*8/9/1958: Written off.

Douglas F4D-1 Skyray/Bu. 139042
  • Delivered to the United States Marines Corps.
    • Redesignated F-6A in 1962.
    • Assigned to VMF(AW)-114 Death Dealers as AB-205, 1958-1959.
    • Struck off charge at NAF Litchfield Park, AZ, April 13, 1964.
Douglas F4D-1 Skyray/Bu. 139042
Three Douglas F4D-1 Skyray (Bu. 134960, Bu. 139042 & Bu. 139051) of VMF(AW)-114 Death Dealers on the catapults of the USS Franklin D. Roosevelt (CVA-42), 1959.
[Source: USMC Photo.]

Douglas F4D-1 Skyray/Bu. 139043
*VMF(AW)-115.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139044
*VMF(AW)-542 as WH-3.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139045
*1958-59: VMF(AW)-114 as AB-xxx.
*1959: VMF(AW)-114 as EK-8.
*1960: VMF(AW)-115 as EK-8.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139046
*1958-59: VMF(AW)-114.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139047
*1961: VMF(AW)-542 as WH-8.
*VU-3 as UF-14.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139048
*1958-59: VMF(AW)-114 as AB-202.
*5/1/1961: Damaged beyond repair in an accident.
*3/4/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139049
*1960: VMF(AW)-115.
*1/14/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139050
*1958: FAWTULANT.
*1960: VF-13 as AK-104.
*1962: VF-13 as AK-106.
*6/10/1962: Crashed into the sea while attempting to land on the USS Shangri La off Southern France.

Douglas F4D-1 Skyray/Bu. 139051
  • Delivered to the United States Marines Corps.
    • Assigned to VMF(AW)-114 Death Dealers, 1958-1960.
      • Recoded as AB-201, 1959.
    • Written off, December 23, 1960.
Douglas F4D-1 Skyray/Bu. 139051
Three Douglas F4D-1 Skyray (Bu. 134960, Bu. 139042 & Bu. 139051) of VMF(AW)-114 Death Dealers on the catapults of the USS Franklin D. Roosevelt (CVA-42), 1959.
[Source: USMC Photo.]

Douglas F4D-1 Skyray/Bu. 139052
*1958: VF-213 as NP-310.
*1959: VMF(AW)-114 as AB-201.
*1960: VMF-314 as VW-4.
*1963: VU-3 as UF-17.
*Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139053
*1958: VF-213 as NP-308.
*9/4/1958: Written off.

Douglas F4D-1 Skyray/Bu. 139054
*1962: VMF(AW)-513 as WF-6.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139055
*VMF(AW)-314.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139056
*1959-60: VF-13 as AK-10x.
*1964: VMF(AW)-115 as VE-11.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139057
*1959: VMF(AW)-314.
*1/2/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139058
*1958: VF-213 as NP-307.
*1960: VF-51 as NF-104.
*1963: VMF(AW)-542.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139059
*1961: VMF-314 as VW-26.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139060
*1958: VF-213 as NP-306.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139061
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139062
*1959: VF-13 as AK-13.
*1960: VF-13 as AK-116.
*1961-62: VF-13 as AK-108.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139063
*VX-4.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139064
*VMF(AW)-115.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139065
*1958: ? as AK-xxx.
*1961: VF-102 as AJ-101 and AJ-111.
*1962-63: VMF(AW)-115 as AG-112. Or as VE-xx at the time of accident?
*1/19/1963: Damaged beyond repair in an accident? Repaired?

Douglas F4D-1 Skyray/Bu. 139066
*1960: VMF(AW)-314.
*12/5/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139067
*1958-59: VMF(AW)-114 as AB-xxx.
*3/21/1962: Damaged beyond repair in an accident.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139068
*VMF(AW)-114.
*VMF(AW)-115.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139069
*1958-60: VF-102 as AK-108.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139070
*1958: VMF(AW-531 as EC-5.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139071
*1959: VMF(AW)-314.
*8/11/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139072
*1958-59: VMF(AW)-114 as AB-200.
*4/13/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139073
*1959: VF-141.
*4/10/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139074
*VMF(AW)-115.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139075
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139076
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139077
*1958-59: VMF(AW)-314 as VW-19.
*1/6/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139078
*VMF(AW-115 as AG-106.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139079
*1962: VMF(AW)-115 as VE-3.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139080
*VF(AW)-3 as PA-8.
*VMF(AW)-215.
*1964: NARTU Olathe, KS as 7K-101.

Douglas F4D-1 Skyray/Bu. 139081
*1958: VF-74 as AF-101.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139082
*4/4/1962: Damaged beyond repair in an accident.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139083
*VMF(AW)-215.
*1959-60: VF-13 as AK-108.
*1961: VF-102 as AJ-1xx.
*1964: NARTU Olathe, KS as 7K-108.

Douglas F4D-1 Skyray/Bu. 139084
*1960-61: VMF(AW)-531 as EC-4.
*1962-63: VMF(AW)-115 as AG-104.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139085
*1961-62: H&MS-24.
*1962: VMF(AW)-115.
*1/17/1962: Written off.

Douglas F4D-1 Skyray/Bu. 139086
*--info needed.

Douglas F4D-1 Skyray/Bu. 139087
*1959: VMF(AW)-115 as VE-6.
*VMF(AW)-115 as AG-102.
*3/13/1964: Struck off charge at BWR FR Dallas, TX.

Douglas F4D-1 Skyray/Bu. 139088
*1959: VF-213 as NP-312.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139089
*1959: VF-141 as NK-2x2.
*1960: VF-51 as NF-xxx.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139090
*1960: VF-13.
*9/16/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139091
*1959: VMF(AW)-115.
*9/21/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139092
*VMF(AW)-314 as VW-1.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139093
*VMF(AW)-115 as VE-13.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139094
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139095
*VMF(AW)-314.
*1963: VMF(AW)-542.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139096
*1959: VF(AW)-3.
*1/6/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139097
  • Delivered to the United States Navy.
    • Assigned to VF(AW)-3 as PA-12.
Douglas F4D-1 Skyray/Bu. 139097
F4D-1 Skyray/Bu. 139097 of VF(AW)-3.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 139098
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139099
*1958: VF-102 as AK-111.
*1958-59: VMF(AW)-114 as AB-xxx.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139100
*1959: VMF(AW)-114.
*1/15/1959: Crashed while landing aboard USS Franklin D. Roosevelt (CVA-42) and fell into the sea. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 139101
*VMF(AW)-314.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139102
*1960: VMF(AW)-314.
*12/20/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139103
*1960-61: VF-74 as AF-xxx.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139104
*1960-61: VF-74 as AF-112.
*1962: VF-13 as AK-1xx.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139105
*1960: VF-74.
*7/6/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139106
*1958: VMF(AW)-513.
*11/19/1958: Written off.

Douglas F4D-1 Skyray/Bu. 139107
*VF(AW)-3 as PA-10.

Douglas F4D-1 Skyray/Bu. 139108
*1959: VX-3.
*3/20/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139109
*1959: VF-74 as AF-105.
*11/20/1959: Crashed into the sea off NAS Oceana, VA after a collision with F4D 139116.

Douglas F4D-1 Skyray/Bu. 139110
*1959: VMF(AW)-314.
*2/10/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139111
*1959: H&MS-15.
*11/9/1962: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139112
*1962: VMF(AW)-542 as WH-23.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139113
*1960-61: VF-74 as AF-106.
*2/28/1962: Damaged beyond repair in an accident.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139114
*VMF(AW)-531 as EC-1.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139115
*1959-60: VF-74 as AF-111.
*3/3/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139116
*1959: VF-74 as AF-1xx.
*11/20/1959: Crashed into the sea off NAS Oceana, VA after a collision with F4D 139109. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 139117
*1959-61: VF-74 as AF-110.
*1963: VF-13 as AK-103.
*1963: Put into storage at NAF Litchfield Park, AZ.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139118
*1959: VF-74 as AF-109.
*11/16/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139119
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139120
*1960-61: VF-13 as AK-106.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139121
*VMF(AW)-115 as VE-3.
*Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139122
*VMF(AW)-115.
*1964: VU-3 as UF-14.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139123
*1961: VMF-513.
*11/20/1961: Written off.

Douglas F4D-1 Skyray/Bu. 139124
*1960: VMF(AW)-314 as VW-17.
*1961: VMF(AW)-542.
*9/5/1961: Written off.

Douglas F4D-1 Skyray/Bu. 139125
*1960: VMF(AW)-314 as VW-18.
*11/16/1963: Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139126
*VF-74.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139127
*1962: VMF(AW)-314 as VW-6.
*1963: VMF-513 as WF-14.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139128
*1962: VMF(AW)-542 as WH-22.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139129
*1963: VMF(AW)-513 as WF-2.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139130
*1959: VMF(AW)-542.
*7/29/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139131
*VMF(AW)-542 as WH-1.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139132
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139133
*Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139134
*1962: VMF(AW)-513 as WF-5.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139135
  • Delivered to the United States Navy.
    • Assigned to VF-74 as AF-1x5, 1960-1961.
    • Transferred to VMF(AW)-114 Death Dealers as EK-21.
    • Struck off charge at NAF Litchfield Park, AZ.
Douglas F4D-1 Skyray/Bu. 139135
Douglas F4D-1 Skyray/Bu. 139135 of VMF(AW)-114 Death Dealers being refueled at MCAS Cherry Point, NC, 1961.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 139136
*VMF(AW)-542 as WH-11.
*11/30/1966: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139137
*1964: VU-3 as UF-10.
*VF-13.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139138
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139139
*1963: VMF-513 as WF-9.
*1/4/1963: Written off.

Douglas F4D-1 Skyray/Bu. 139140
*VF-74 as AF-104.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139141
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139142
*VMF(AW)-513 as WF-13.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139143
*Modified to YF4D-1.
*1958-61: NATC as 143.
*1964: VU-3 as UF-19.
*Converted to DF-6A drone controller.
*1/7/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139144
*1959: VMF(AW)-513 as WF-10.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139145
*1962: VMF(AW)-115 as VE-00.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139146
*as AF-114.
*1962: VF-13.
*1/8/1962: Crashed on a flight off USS Shangri La. Pilot was killed.

Douglas F4D-1 Skyray/Bu. 139147
*1959: VF-141 as NK-204.
*1960: VF-51 as NF-104.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139148
*1962: VMF-314 as VW-16.
*VMF(AW)-542.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139149
*1960: VF-74 as AF-105.
*1962: VF-13 as AK-107.
*VMF(AW)-542 as WH-16.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139150
*1958: VF-74 as AF-101.
*11/24/1958: Written off.

Douglas F4D-1 Skyray/Bu. 139151
*1961: VMF(AW)-542 as WH-17.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139152
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139153
*VF(AW)-3.
*Converted to DF-6A.
*1964: VU-3 as UF-12.
*7/24/1964: Crashed.

Douglas F4D-1 Skyray/Bu. 139154
*1960: VF-13.
*1/22/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139155
*1964: VMF(AW)-115 as VE-14.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139156
*1961: VMF-314.
*11/10/1961: Written off.

Douglas F4D-1 Skyray/Bu. 139157
*1960: VMF(AW)-513.
*9/26/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139158
*VMF(AW)-114.
*VMF(AW)-115.
*1962: VMF(AW)-115 as EK-20.
*1962: VMF(AW)-531 as EC-20.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139159
*VMF(AW)-115.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139160
*1960: VF-51 as NF-111.
*1961: VMF(AW)-115.
*4/24/1961: Written off.

Douglas F4D-1 Skyray/Bu. 139161
*1964: VU-3 as UF-7.
*5/21/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139162
*1959: VF(AW)-3 as PA-11.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139163
  • Delivered to the United States Navy.
    • Assigned to VF(AW)-3 as PA-55, 1959.
    • Written off, February 8, 1959.
Douglas F4D-1 Skyray/Bu. 139163
Two Douglas F4D-1 Skyrays (Bu. 139163 and 134848) of VF(AW)-3 Blue Nemesis at NAS North Island, San Diego, CA, 1959.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 139164
  • Delivered to the United States Navy.
    • Assigned to VF(AW)-3 as PA-17.
    • Struck off charge at NAF Litchfield Park, AZ, May 21, 1965.


Douglas F4D-1 Skyray/Bu. 139165
  • Delivered to the United States Navy.
    • Assigned to VF-141 as NK-206, 1959.
    • Transferred to VMF(AW)-542 as WH-9.
    • Struck off charge at NAF Litchfield Park, AZ, May 21, 1965.
Douglas F4D-1 Skyray/Bu. 139165
Douglas F4D-1 Skyrays (Bu. 139165 & 134884) of VF-141 ready to launch from the USS Ranger (CVA 61), 1959.
[Source: U.S. Navy]

Douglas F4D-1 Skyray/Bu. 139166
*1964: VU-3 as UF-9.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139167
*1959: VF-213.
*3/19/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139168
*1961: VMF(AW)-513.
*8/27/1961: Written off.

Douglas F4D-1 Skyray/Bu. 139169
*1960: VF-74 as AF-111.
*8/12/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139170
*1959: VMF(AW)-542.
*1/31/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139171
*1/7/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139172
*1960: VMF(AW)-314.
*2/10/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139173
*VMF(AW)-513 as WF-1.
*1963: VMF(AW)-542 as WH-1.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139174
*1959: VMF(AW)-542.
*3/6/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139175
*--info needed.

Douglas F4D-1 Skyray/Bu. 139176
*1959: VF-213.
*10/10/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139177
*1958: FASRON 8.
*1958: VMF(AW)-115.
*1959: VF-141 as NK-207.
*1959: FASRON 7.
*1959: VF-213.
*1960: VMF(AW)-314.
*1960: VMF(AW)-513.
*1960: VMF(AW)-542.
*1962: VMF-513 as WF-18.
*1962: VF-13 as AK-103.
*6/1963: Put into storage at NAF Litchfield Park, AZ.
*1965-69: Naval Test Pilot School.
*11/25/1969: Struck off charge.
*Was displayed at the Air/Ground Museum at Quantico, VA.
*Currently stored at the Flying Leatherneck Museum at MCAS Miramar, CA for restoration.

Douglas F4D-1 Skyray/Bu. 139178
*VMF(AW)-314.
*10/16/1963: Struck off charge at O&R NAS North Island, CA.
*Was a derelict at the Seabee Base at Port Hueneme, CA into the 1970s.

Douglas F4D-1 Skyray/Bu. 139179
*1963: VMF(AW)-542 as WH-10.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139180
*1959: VF-213 as NP-xxx.
*1963: VMF(AW)-513.
*3/2/1963: Written off.

Douglas F4D-1 Skyray/Bu. 139181
*1960: VMF-314 as VW-6.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139182
*1959: VF-213 as NP-306.
*VMF(AW)-542 as WH-19.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139183
*VMF(AW)-115.
*1962: VMF(AW)-531 as EC-14.
*1962: VMF(AW)-114.
*11/2/1962: Written off.

Douglas F4D-1 Skyray/Bu. 139184
*VF-74 as xx-101.
*11/6/1962: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139185
*1959-61: VF-74 as AF-102.
*1962: VF-13 as AK-111.
*10/30/1964: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139186
*1959: ? as NF-107.
*1961: VMF-314 as VW-11.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139187
*VMF(AW)-115.
*VMF(AW)-531 as EC-10.
*1959: VF-213 as NP-302.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139188
*1960: VMF(AW)-314.
*4/20/1960: Written off.

Douglas F4D-1 Skyray/Bu. 139189
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139190
*VF-141.
*VMF(AW)-115.
*Struck off charge at O&R NAS North Island, CA.

Douglas F4D-1 Skyray/Bu. 139191
*1959: VF-213 as NP-308.
*VMF(AW)-115.
*1962: VMF(AW)-531 as EC-2.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139192
*1960: VF-51 as NF-102.
*VMF(AW)-115.
*1962: VMF(AW)-114.
*9/19/1962: Written off in Japan.
*Was a hulk at NAS Atsugi, Japan for a time.

Douglas F4D-1 Skyray/Bu. 139193
*VMF(AW)-513 as WF-3.
*Converted to DF-6A drone controller.
*1/7/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139194
*1961: VMF(AW)-542 as WH-12.
*Converted to DF-6A drone controller.
*1/7/1965: Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139195
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139196
*1959: VF-213 as NP-309.
*1962-63: VMF(AW)-115 as AG-105.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139197
*VMF(AW)-114 as EK-10.
*VMF(AW)-115.
*1959: VF-51 as NF-107.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139198
*? as WH-18.
*1960: VF-51 as NF-108.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139199
*VMF(AW)-115.
*1961: VMF(AW)-531 as EC-9.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139200
*1960: VF-74 as AF-107.
*1962: VMF(AW)-115 as AG-109.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139201
*VMF(AW)-542 as WH-8.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139202
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139203
*1959: VF-13.
*5/28/1959: Written off.

Douglas F4D-1 Skyray/Bu. 139204
*1960: VF-13 as AK-109.
*6/1/1962: Damaged beyond repair in an accident.
*11/14/1963: Struck off charge at O&R NAS Jacksonville, FL.

Douglas F4D-1 Skyray/Bu. 139205
*1963: VU-3.
*1/14/1963: Written off.

Douglas F4D-1 Skyray/Bu. 139206
*1959: VF-13 as AK-07.
*1960: VF-74 as AF-xxx.
*Struck off charge at NAF Litchfield Park, AZ.

Douglas F4D-1 Skyray/Bu. 139207
*1959-60: VF-13 as AK-100.
*1960-61: VF-74 as AF-104.
*1962-63: VMF(AW)-115 as AG-110.
----------------------------END-----------------------------------------

For their assistance in various parts of this project, I would like to give thanks to the following individual people...

Tom Bispo
Ron Lewis
Ron Picciani
Rick Centore
Alain Laurent
Harold (Woody) Woodrom
Ted Berwald
Sid Nanson
Olivier van Gorp
John McKenna
Bill Stein
Phil Oestricher
Luis Bonanni
Cora Revak
Lun K.Y.
WOULD YOU LIKE
TO SUPPORT
THIS SITE?
(Click Here For Info)
Or
WARBIRDS RESOURCE GROUP:
WARBIRD REGISTRY • U.S.A.A.F • U.S. NAVY • BRITISH • LUFTWAFFE • JAPANESE • RUSSIAN • VIETNAM ERA • ALLIED • POWERPLANTS • TRIPLE AAA • FORGOTTEN AVIATION • WARBIRD INFORMTATION XCHANGE • MILITARY MOVIE GUIDE
 Layout and design copyright © 2022 by the Scott Rose and the Warbirds Resource Group.
